Feature
Specification
Capacity" Up to 16,000 Ibs/hr
Crusher Motor: 3 HP TEFC
Conveyor Motor: 3/4 HP TEFC
Hopper Size: 718 cu. yd. (67" wide)
Discharge Height: 48"
Dimensions (LxWxH): 11' 10" x 67" × 9' 5"
Cullet Density:~80 lbs/cu. ft.

_______________________________________

Crushing Mechanism: Uses a rotating steel drum with hardened bars and a 3/4" thick steel breaker plate.
• Conveyor System: Features a PVC 200 conveyor with 1-1/2" cleats and an enclosed belt-return to minimize glass spillage.
• Durability: All-steel unitized construction with a 3/16" thick steel crushing chamber.
• Mobility: Equipped with 6" industrial steel casters for movement within a facility.
• Safety: Includes NEMA-3R enclosures for outdoor use and safety interlocks on the crusher access door.
